4IPNET MSG100

Networking

• Support Router, NAT mode
• Support Static IP, DHCP, PPPoE mode on WAN interfaces and PPTP (WAN 1 only)
• Controllable LAN ports requiring authentication
• Support IP Plug and Play (IP PnP)
• Built-in DHCP server and support for DHCP relay
• Support NAT:
  (1) IP/Port Destination Redirection
  (2) DMZ Server Mapping
  (3) Virtual Server Mapping
  (4) H.323 Pass-Through
  (5) SIP Pass-Through
• Support static route
• Support Wake on LAN, Web-based utilities (Ping, Trace Route and ARP) and Dynamic DNS
• Walled Garden (free surfing zone): 20
• Support MAC Address Pass-Through
• HTTP Proxy Servers: 10
• WAN failover and local balancing on dual WANs
• Support multiple service zones in Port-based or Tag-based mode

Security

• Local VPN tunnels to enhance wireless security: 50
• Client-to-site remote VPN of PPTP over public Internet: 10
• Site-to-site VPN tunnels over public Internet: 3
• Support VPN Pass-Through (IPSec and PPTP)
• Support built-in DoS attack protection
• Support MAC Access Control List
• Support user Black List: 5 lists x 40 sets
• Allows MAC address and user identity binding for local user authentication
• Support QoS and WMM

Connectors and Display

• WAN Ports: 2 x 10BASE-T/100BASE-TX RJ-45
• LAN Ports: 4 x 10BASE-T/100BASE-TX RJ-45
• Console Port : 1 x RS-232 DB9
• LED Indicators: 1 x Power, 1 x Status, 2 x WAN, 4 x LAN

Environment

• Operating Temperature: 0 ~ 40°C
• Storage Temperature: -20 ~ 65 °C

Certifications

• CE, FCC
• RoHS compliance

User Management

• Simultaneous support for multiple authentication methods (Local, POP3(S), LDAP, RADIUS, NT Domain, on-demand and SIP)
• Role-based access control (including Firewall policies, Specific route, Login Schedule, and Bandwidth management)
• Support time-based firewall policy
• User Session Management:
  (1) SSL protected login portal page
  (2) Support multiple logins with one single account
  (3) Session idle timer
  (4) Session/account expiration control
  (5) Email message with a hyperlink and login reminder for accessing login page
  (6) Windows domain transparent login
  (7) Configurable login time frame
• Instant account (200 accounts) generation for guests by authorized users without IT’s intervention
• User account roaming support
• Support local account grouping to classify users

System Administration

• Multi-lingual, web-based management UI
• Customizable login and logout portal pages
• SSH remote management
• Remote firmware upgrade
• NTP time synchronization
• Console management interface support (CLI)
• Backup and restore of system configuration
• SNMP v2 support

Monitoring and Reporting

• Status monitoring of on-line users
• Monitoring of IP-based network devices
• WAN connection detection and failure alert message
• Support SYSLOG for diagnosing, troubleshooting and logging
• User traffic session log
• Traffic history report in an automatic email to administrator
• Support RADIUS accounting
• Notification email of status monitoring and reporting

Hardware Specifications

• Built-in real-time clock

Physical and Power

• Power Adapter: 100~240 VAC, 50/60 Hz
• Form Factor: Mini-book
• Dimensions (W x D x H): 11.8" x 6.1" x 1.7" (300 mm x 155 mm x 43 mm)
• Weight: 2.5 lbs (1.15 kg)
